Dimensions: 180mm x 110mm x 85mm
Weight: 433g
Voltage/Current: 5VDC+/-10%@500mA
Image(Pixels): 640 pixels(H) x 480 pixels(V)
Light Source: Aiming:617 nm LED; illumination: 3500K LED
Field Of View: 40°(H)x32°(V)
Roll/Pitch/Yaw: Pitch ±65° / Yaw 360° / Roll ±60°
Print Contrast: 25% minimum reflective difference
Interfaces Supported: USB, RS232
Motion Tolerances: ≥2m/s
Decode Capability: 1D: UPC, EAN, Code 128, Code 39, Code 93, Code 11, Matrix 2 of 5, Codabar,
Interleaved 2 of 5, MSI Plessey, GS1 Databar, China Postal, Korean Postal, etc.
2D: PDF417, MicroPDF417, Data Matrix, Maxicode, QR Code, Micro QR, Aztec, Hanxin, etc.
Operating Temp: 0° to 50° C
Storage Temp: -40° to 70° C
Humidity: 0% to 95% relative humidity, non-condensing
Shock Specs: withstand 1.5m(5’) drops
Ambient Light: 100,000 Lux
Code 39 (20 mil): 20mm-370mm
Code 39 (5.13 mil): 30mm-120mm
PDF (6.88 mil): 10mm-170mm
DM (10 mil): 20mm-170mm
UPC-A 100% (13 mil): 20mm-360mm
QR (20 mil): 0mm-330mm
